NLSA

This project provides a MATLAB implementation of nonlinear Laplacian spectral analysis (NLSA) and related kernel algorithms for feature extraction and prediction of observables of dynamical systems.

Usage

Clone down the project repository:

git clone https://github.com/dg227/NLSA

Launch MATLAB, cd into the project’s directory, and add /nlsa to the MATLAB search path. This can be done by executing the MATLAB command:
```
addpath(genpath('nlsa'))
```

Examples

Rectification of variable-speed periodic oscillator using Koopman eigenfunctions:
```
/examples/circle/demoKoopman.m
```
Extraction of an approximately cyclical observable of the Lorenz 63 (L63) chaotic system using kernel integral operators with delays:
```
/examples/circle/demoNLSA.m
```
Kernel analog forecasting of the L63 state vector components:
```
/examples/l63/demoKAF.m
```

Implementation

NLSA implements a MATLAB class nlsaModel which encodes the attributes of the machine learning procedure to be carried out. This includes:

Specification of training and test data.
Delay-coordinate embedding.
Pairwise distance functions.
Density estimation for variable-bandwidth kernels.
Symmetric and non-symmetric Markov kernels.
Koopman operators.
Projection and reconstruction of target data.
Nystrom out-of-sample extension.

Each of the elements above are implemented as MATLAB classes. See /nlsa/classes for further information and basic documentation.

Results from each stage of the computation are written on disk in a directory tree with (near-) unique names based on the nlsaModel parameters.

Known issues

In Windows environments, errors can occur due to long file/directory names.

Acknowledgment

Research funded by the National Science Foundation (grants DMS-1521775, 1842538, DMS-1854383) and Office of Naval Research (grants N00014-14-1-0150, N00014-16-1-2649, N00014-19-1-2421).
